CE MDR Approval Portable One-button Infrared Forehead Thermometer for Baby And Adult

Model no.: DET-3022
Unit dimension: 8.3 x 4.2 x 4.2 cm
Weight: 45g (with battery)
Measuring range: 34.0°C - 43.0 °C
Measuring accuracy: ±0.2 °C between 35.5 - 42.0 °C
Measuring distance: less than 5cm
Battery: one pc of CR2032 battery, replaceable
  • DET-3022

  • OEM available


DET-3022 infrared forehead thermometer is colorful with compact portable design.

One button for both setting and temperature measuring.

1 second measurement makes it easy for baby fever management.

1. Probe

2. Test Button

3. Battery Cover

4. Display

DET-3022 description


Model DET-3022
Type Infrared Forehead
Response Time 1 second
Memory 30 Memories
Range 34.0°C- 43.0°C (93.2 °F-109.4 °F)
Accuracy ±0.2°C,35.5°C -42.0°C(±0.4°F,95.9 °F-107.6°F)
Obeject Mode Yes
Fever Alarm Over 37.8°C (100.4°F)
Backlight Optional
Display size 23.3x23mm
Power Source CR2032,replaceable
Probe Cover ——
Battery Life About 3000 readings
Unit Dimension 8.3X4.2X4.2cm
Unit Weight Approx. 45grams
Packing 1 pc / Gift box;200 pcs / Carton
Carton Dimension Approx. 48.5X35X45cm
Carton Weight Approx. 17kg


Basic function:


●Dual scale with °C/°F

●Replaceable battery

●Automatic power-off

Featuring on:

●Portable with integrated lifting ring, put in your pocket or bag any time

●Non-contact digital forehead thermometer measuring on forehead

●1 reading memory

●1 second reading

●4-color backlight optional


Q: What is the measuring distance of this small forehead thermometer?

A: The reading will be accurate when the measuring distance be less than 5cm, for both body and object temperature.

Q: How to change the forehead mode and object mode?

A: To switch between measurement modes on the thermometer, first ensure that it's turned off. Then, press and hold the Test Button. While holding the button, you'll see the forehead symbol and the object symbol alternately displayed. Keep holding the Test Button until you reach the desired mode. Once you're in the mode you want, simply release the Test Button, and the thermometer will automatically switch to that measurement mode.

Q: How does backlight work?

A: In Forehead mode:

1.The display will be lighted GREEN for 3 seconds when a measurement is completed with a reading less than 37.3C(99.1F).

2.The display will be lighted YELLOW for 3 seconds when a measurement is completed with a reading less than 37.8℃(100.0TF).

3.The display will be lighted RED for 3 seconds when a measurementis completed with a reading equal to or higher than 37.8℃(100.0F).

In Object mode:

The display will be lighted GREEN for 3 seconds when ameasurement is completed.
