Product Description
1 Introduction
Intended use/Indications for use:
The Compressor Nebulizer include air compressor that provide a source of compressed air with a jet (Pneumatic) nebulizer to convert certain inhalable drugs into an aerosol form for inhalation by a patient. The device can be used with adult or pediatric patients(2 years and older) in the home, hospital, and sub-acute settings.
Name of disease or condition:
Asthma, Chronic obstructive pulmonary disease (COPD),Cystic fibrosis, Respiratory tract
infection, etc disease of respiratory system.
Patient population:
adults or children (2 years and older)
Intended user:
healthcare person or lay person
2 Safety Instructions
Cautions
1. The product should never be left unattended when plugged in.
2. The patient is an intended operator, close supervision is necessary when this product is used by, or near children or disabled individuals.
3. Operate the device only as intended. Do not use the device for any other purpose
4. Always ensure that the air vents are not blocked or obstructed in any way.
5. Do not disassemble the nebulizer or attempt to repair it; any attempt for repair should be completed only by qualified technical personnel.
Warning
1. The nebulizer can work with the solution or suspensions only, but not with emulsions or high viscosity drugs.
2.Operate the device only as intended. Do not use the nebulizer for any other purpose or in a manner inconsistent with these instructions.
3.For type, dose, and regime of medication follow the instructions of your physician or licensed healthcare practitioner.
4.Never use any liquid in the nebulizer other than those prescribed by your doctor. Liquids such as cough medicines or essential oils can harm both the machine and the patient.
3 Technical Data
SPECIFICSTIONS |
Model: | NB-1103 |
Type: | Compressor Nebulizer |
Power supply: | AC 230V, 50 Hz |
Input Power: | ≤ 80VA |
Operating Mode: | Continuous Operation |
Sound Level: | ≤ 65dB(A) |
Gas Flow Volume Rate: | ≥6.5L/min |
Dimensions: | Approx. 11.2" (w) × 6.1" (h) × 5.3" (d) (286 mm × 154 mm × 134.5 mm) |
Weight: | Approx. 1.57kg (Compressor only) |
Operating Temperature/Humidity/ Atmospheric Pressure | +5°C to +40°C (+41°F to +104°F)/15% to 90% RH/86 kPa to 106 kPa |
Storage and Transport Temperature/Humidity/ Atmospheric Pressure | –20°C to +55°C (–4°F to +131°F)/5% to 93% RH/70 kPa to 106 kPa |
Normal Working Pressure: | 50kPa~180kPa |
Abnormal Working Pressure: | 190kPa~320kPa |
Functions: | Switch indicator, Working state indicator, Atomiazing time setting, Buzzer, Power cord storage, Nebulizer kit storage |
Classification: | Class II equipment, Type BF applied part |
Contents: | 1 Compressor nebulizer unit, 5 Air Filters, 1 Owner’s manual |
The Standard Accessories: | Air filter(×5 pcs) |
Applied Parts: | Mask, Mouthpiece |
Accessible Parts: | Shell of Compressor |
Fuses: | 5JF 1.6AL 250V |
Features
1. Large amount of fog, saving time
2. Fine atomization, easily absorbed
3. Large storage space for accessories
4. Super long Air duct, free movement
5. Low residue and high utilization rate
6. Toy shape, turn inhalation into fun game
7. Creates a low noise inhalation environment
8. Double suction mode of mask and suction nozzle
9. Green indicator lights indicating on/off status
10.Time setting, 15 second countdown buzzer reminder
Introduction:Experience innovative respiratory care with our Car Shape Cute Baby Cartoon Compressor Nebulizer, specifically designed to provide effective and adorable treatment for pneumonia. The NB-1103 combines advanced technology with a child-friendly design, ensuring a seamless and enjoyable nebulization experience for your little ones.
Technical Specifications:Transforming Treatment Into Fun Adventures
High-Performance Nebulization: The NB-1103 boasts a powerful compressor, delivering a consistent and efficient nebulization process.
Particle Size Control: Achieve optimal respiratory benefits with our precision-controlled particle size, ensuring effective medication delivery to the respiratory tract.
Quiet Operation: Designed with a focus on a peaceful environment, the NB-1103 operates with minimal noise, making it suitable for various settings, including nighttime use.
Versatile Applications:Tailored for Various Respiratory Needs
Pediatric Respiratory Therapy: Specifically crafted for pediatric use, the cute car shape and cartoon design turn treatment into an engaging adventure, helping children feel comfortable during nebulization.
Effective Pneumonia Treatment: The NB-1103 is a reliable companion for pneumonia treatment, delivering medication with precision to target respiratory infections.
User-Friendly Operation:Simple, Safe, and Convenient
One-Touch Operation: The easy-to-use one-touch operation ensures hassle-free nebulization, making it a convenient choice for parents and caregivers.
Safety Features: Prioritize your child's safety with built-in features such as overheat protection and overload safeguards, providing peace of mind during treatment sessions.
Quality Craftsmanship:Durability Meets Adorability
Premium Materials: Crafted from high-quality materials, the NB-1103 guarantees durability, ensuring a long lifespan for consistent respiratory support.
Adorable Design: The cute car shape and baby cartoon visuals add a delightful touch to the nebulizer, transforming it into a friendly companion for your child's health journey.
Accessories and Extras:Enhance Your Nebulization Experience
Comfortable Face Masks: Included face masks ensure a comfortable fit for various age groups, catering to the diverse needs of pediatric patients.
Extended Tubing: Benefit from flexibility during nebulization with the extended tubing, allowing ease of movement for your child.
Certifications and Trust:Your Child's Health in Reliable Hands
Medical Device Certification: The NB-1103 is certified as a medical device, meeting stringent quality standards to provide reliable respiratory care.
Customer Testimonials: Read glowing reviews from satisfied parents who have experienced the positive impact of the NB-1103 on their child's respiratory health.
Guaranteed Satisfaction:Our Commitment to Your Child's Well-Being
Elevate your child's respiratory care with the Car Shape Cute Baby Cartoon Compressor Nebulizer NB-1103 – where advanced technology meets delightful design. Order now and embark on a journey towards effective and enjoyable nebulization for your little ones.
