Availability: | |
---|---|
NB-1004
OEM available
NB-1004 compressor nebulizer is compact design but powerful for home use or clinical use nebulization. One button for easy operation. Ideal for home breath care.
1 Introduction
Intended use/Indications for use:
The Compressor Nebulizer include air compressor that provide a source of compressed air with a jet (Pneumatic) nebulizer to convert certain inhalable drugs into an aerosol form for inhalation by a patient. The device can be used with adult or pediatric patients(2 years and older) in the home, hospital, and sub-acute settings.
Name of disease or condition:
Asthma, Chronic obstructive pulmonary disease (COPD),Cystic fibrosis, Respiratory tract
infection, etc disease of respiratory system.
Patient population:
adults or children (2 years and older)
Intended user:
healthcare person or lay person
2 Safety Instructions
Cautions
1. The product should never be left unattended when plugged in.
2. The patient is an intended operator, close supervision is necessary when this product is used by, or near children or disabled individuals.
3. Operate the device only as intended. Do not use the device for any other purpose
4. Always ensure that the air vents are not blocked or obstructed in any way.
5. Do not disassemble the nebulizer or attempt to repair it; any attempt for repair should be completed only by qualified technical personnel.
Warning
1. The nebulizer can work with the solution or suspensions only, but not with emulsions or high viscosity drugs.
2.Operate the device only as intended. Do not use the nebulizer for any other purpose or in a manner inconsistent with these instructions.
3.For type, dose, and regime of medication follow the instructions of your physician or licensed healthcare practitioner.
4.Never use any liquid in the nebulizer other than those prescribed by your doctor. Liquids such as cough medicines or essential oils can harm both the machine and the patient.
3 Technical Data
SPECIFICSTIONS | |
Model: | NB-1004 |
Type: | Compressor Nebulizer |
Rating(AC adapter): | AC 100 - 240V , 50/60 Hz, 0.5A |
Rating(Compressor Nebulizer): | DC 12V, 0.9A |
Power Consumption: | 10.8VA |
Operating Mode: | Continuous Operation |
Sound Level: | ≤ 60dB(A) |
Gas Flow Volume Rate: | ≥5L/min |
Dimensions: | Approx. 4.4" (w) × 3.7" (h) × 1.8" (d) (111.5 mm × 95 mm × 45 mm) |
Weight: | Approx. 0.20kg (Compressor only) |
Operating Temperature/Humidity/ Atmospheric Pressure | +5°C to +40°C (+41°F to +104°F)/15% to 90% RH/86 kPa to 106 kPa |
Storage and Transport Temperature/Humidity/ Atmospheric Pressure | –20°C to +55°C (–4°F to +131°F)/5% to 93% RH/70 kPa to 106 kPa |
Normal Working Pressure: | 45kPa~85kPa |
Abnormal Working Pressure: | 90kPa~150kPa |
Classification: | Class II equipment, Type BF applied part |
Contents: | 1 Compressor nebulizer unit, 5 Air Filters, 1 Owner’s manual |
The Standard Accessories: | Air Filter(×5 pcs), An AC/DC Adapter(DC 12V) |
Applied Parts: | Mask, Mouthpiece |
Accessible Parts: | Shell of Compressor |
Fuses: | 5JF 1.6AL 250V |
Unparalleled Performance for Pediatric Respiratory Care
Discover the NB-1004, a cutting-edge Home Nebulizer designed exclusively for kids. This Medical Compressor Nebulizer promises unparalleled performance, providing optimal respiratory care in the comfort of your home.
Technical Excellence
Precision Engineering: The NB-1004 boasts a state-of-the-art compressor system with a precise pressure range, ensuring efficient aerosol delivery for respiratory treatments.
Fine Particle Nebulization: Our advanced technology ensures the production of fine particles, optimizing medication absorption and enhancing treatment effectiveness.
Versatility and Practicality
Multifunctional Usage: Tailored for pediatric respiratory needs, the NB-1004 is versatile, suitable for a range of treatments including asthma management and respiratory infections.
User-Friendly Operation: With a one-touch operation, the NB-1004 is designed for simplicity. Its intuitive interface allows for easy handling, making it ideal for parents and caregivers.
Safety First
Overheat Protection: Prioritizing safety, the NB-1004 includes overheat protection, ensuring a secure and worry-free respiratory treatment experience.
Reliable Performance: Built with high-quality materials and precision manufacturing, the NB-1004 guarantees reliability, providing consistent and dependable performance.
Quality Construction
Durable Materials: Crafted from durable materials, the NB-1004 is designed to withstand daily use, ensuring longevity and durability.
Sleek Design: The compact and sleek design adds a touch of modernity to your home while maintaining the functionality required for effective respiratory care.
Comprehensive Accessories
Complete Kit: The NB-1004 comes with a comprehensive set of accessories, including masks and tubing, ensuring a hassle-free and complete nebulization experience.
Accessory Functionality: Each accessory serves a specific purpose, enhancing the overall usability of the NB-1004 and catering to diverse respiratory care needs.
Whisper-Quiet Operation
Low Noise Level: With a low noise level during operation, the NB-1004 is perfect for nighttime use, providing a quiet and peaceful environment for your child's respiratory treatments.
Trusted Brand, Certified Quality
Medical Device Certification: The NB-1004 is certified as a medical device, meeting stringent quality standards for respiratory care equipment.
Exceptional After-Sales Support
Warranty Coverage: Enjoy peace of mind with our warranty coverage, ensuring your investment is protected.
Customer Service Excellence: Our dedicated support team is ready to assist you with any queries or concerns, providing exceptional customer service throughout your ownership of the NB-1004.
Elevate your child's respiratory care with the NB-1004 Home Nebulizer – where innovation, safety, and effectiveness converge. Trust in a brand that prioritizes your family's well-being.
