CE MDR Approved Non Contact Medical Digital Infrared Thermometer Baby Forehead Thermometer

Share to:

CE MDR Approved Non Contact Medical Digital Infrared Thermometer Baby Forehead Thermometer

DET-3017 Digital Forehead Thermometer delivers safe, accurate, and convenient non-contact measurements with distance indication and multiple optional features.

Unit Dimension:	15.5 x 3.92 x 4.94 cm
Battery:	2 pcs of AAA 1.5V batteries
Nature of Business:	Medical Device Manufacturer & Global Exporter
Service Offering:	OEM / ODM Available
Availability:



Inquire Add to Basket

Model:
DET-3017
Brand:
Joytech / OEM

Product Description

Parts & Functions

Specifications

Factory Profile

The DET-3017 Digital Forehead Thermometer is designed to provide fast and reliable temperature readings with a maximum of 30 memory records, making it ideal for household or professional use.

Its distance indicated light ensures accurate positioning, solving one of the most common issues with infrared thermometers.

Simply aim at the center of the forehead within 5 cm to get an accurate result in just 1 second.

The thermometer also offers optional features such as Bluetooth connectivity for health tracking, vibration notification, and a 4-color backlight for easy interpretation of results.

With automatic power-off, dual scale (°C/°F), and talking function available, the DET-3017 combines safety, accuracy, and convenience in a compact design.

Safty Notice: Please read all instructions carefully before using the device.

Measure on forehead

Non-contact

30 reading memories

1 second reading

Dual scale with °C/°F

Acoustic reading signal

Talking optional

4 colors backlight

Bluetooth optional

Vibration optional

Distance sensor optional

Automatic power-off

FAQ

Q: What is the application for the device?

There is no gender or age limitation for using infrared forehead thermometer. You can not only measure for body temperature, but also measure the object or environment temperature in reasonable range.

Q: How to change Celsius to Fahrenheit of this model?

With the DET-3017 forehead thermometer off, press and hold Setting Button to enter into setting mode. Press Test Button to select the scale unit you want.

Q: How to use the convergence light of the forehead thermometer DET-3017?

With the thermometer on, press and hold the Test Button, you will see two red rays. Adjust your position to converge two rays into one point then the measurement should be the most accurate.

Q: Why you choose Joytech？

We have more than 20 years of experience in R&D, manufacturing and sales for home use medical devices, familiar with the market, understand the rules of the industry, we have a professional team and first-class quality, can meet all your needs. Joytech factory and products are passed global standards such as ISO13485, BSCI, CE MDR and FDA 510k listing.

The DET-3017 Digital Forehead Thermometer is designed with a clear layout and intuitive controls, making it simple and convenient to use. Each part plays a key role in ensuring accurate, efficient, and user-friendly temperature measurement.

1. Probe – Detects infrared signals from the forehead for precise non-contact measurement.

2. Test Button – Initiates the temperature reading with a single press.

3. Voice Switch – Enables or disables the talking function for flexible operation.

4. Setting Button – Allows adjustment of thermometer settings, such as °C/°F selection and other options.

5. Battery Cover – Protects the replaceable battery compartment, ensuring long-lasting use.

6. Display – Shows temperature readings clearly, with optional 4-color backlight for easy interpretation.

DET-3017 description

Model	DET-3017
Type	Infrared Forehead
Response Time	1 second
Memory	30 Memories
Range	34.0°C- 43.0°C (93.2 °F-109.4 °F)
Accuracy	±0.2°C,35.5°C -42.0°C(±0.4°F,95.9 °F-107.6°F)
Obeject Mode	Yes
Fever Alarm	≥ 37.8°C (100.0°F)
Backlight	Optional
Display size	22.3x27.3mm
Power Source	2“AAA” batteries
Probe Cover	No
Battery Life	About 3000 readings
Unit Dimension	15.5X3.9X4.9cm
Unit Weight	Approx. 97grams
Packing	1 pc / Gift box;60 pcs / Carton
Carton Dimension	Approx. 59x35.5x32.5cm
Carton Weight	Approx. 14kg

We are a leading manufacturer that specialize in home medical devices over 20 years, which covers infrared thermometer, digital thermometer, digital blood pressure monitor, breast pump, medical nebulizer, pulse oximeter, and POCT lines.

OEM / ODM services are available.
All products are designed and manufactured inside the factory under ISO 13485 and are certificated by CE MDR and pass US FDA, Canada Health, TGA, ROHS, REACH, etc.

In 2023, Joytech's new factory became operational, occupying over 100,000㎡ of built-up area. With a total of 260,000㎡ dedicated to R&D and the production of home medical devices, the company now boasts state-of-the-art automated production lines and warehouses.

We warmly welcome all the customers' visting, it's only 1 hour by high-speed rail from Shanghai.
