Extra Large Display Dual Power Supply Intelligent Blood Pressure Monitor with Ecg

Share to:

Extra Large Display Dual Power Supply Intelligent Blood Pressure Monitor with Ecg Optional

Digi tal upper arm BP monitor with optional ECG, large touch display, and dual power supply for convenient and accurate home health tracking.

Certificates:	ISO13485, CE , FDA
Package:	1pc/cuff / travel box / user manual / giftbox ; 24pcs/carton
Nature of Business:	Medical Device Manufacturer & Global Exporter
Service Offering:	OEM / ODM Available
Availability:



Inquire Add to Basket

Model:
DBP-6177
Brand:
Joytech / OEM

Product Description

Specifications

Factory Profile

The DBP-6177 digital blood pressure monitor is intended for measurement the systolic and diastolic blood pressureand pulse rate from upper-arm of adults and adolescents over the age of 12 by using a non-invasive technique.

BPM & ECG Monitoring

Model: DBP-6177
Power Source: 3*AAA(replacement) and rechargeable Type C
Packaging: 1pc/cuff / travel box / user manual / giftbox
Packing: 24pcs/carton ; Carton Dimension : 34X34X30cm
Optional for ECG, Bluetooth, Backlight, Voice abroad .

Measure on inflation

ECG Test optional

Bluetooth® optional

Talking optional

Backlight optional

Irregular heartbeat detection

Blood pressure risk indicator

2×150 memories with date and time

Low battery detection

3"AAA" batteries or Type-C

Average last 3 results

Large display

Sensitive touch buttons

Automatic power-off

photobank

FAQ

Q1: What's the difference between DBP-6177, DBP-6277B, and DBP-6677B?
All three models share the same housing design, with slight differences in display.

DBP-6177 is the basic model, offering standard blood pressure measurement.
DBP-6277B adds Bluetooth® connectivity for app pairing and data tracking.
DBP-6677B includes ECG measurement along with Bluetooth®, providing advanced heart health monitoring in one device.

Q2: How can I get some samples?

Please feel free to contact us by e-mail or Alibaba for any samples. We are honored to offer your samples.

Q3: What certificates did you approve?

Our factory has gained ISO9001, ISO13485, CE, MDE CE, FDA, REACH, RoHS authentication.

Model	DBP-6177
Type	Up-Arm
Measurement Method	Oscillometric Method
Pressure Range	0 to 299mmHg
Pulse Range	30 to 180 Beat/ Minute
Pressure Accuracy	±3mmHg
Pulse Accuracy	±5%
Display Size	8.3x5.3cm
Memory Bank	2x60 (Maximum 2x150)
Date & Time	Month+Day+Hour+Minute
IHB Detection	YES
Blood Pressure Risk Indicator	YES
Average Last 3 Results	YES
Included Cuff Size	22.0-36.0cm ( 8.6''- 14.2'' )
Low Battery Detection	YES
Automatic Power-off	YES
Power Source	3 “AAA” or Type C
Battery Life	About 2 months (test 3 times per day, 30 days/per month)
Backlight	Optional
Talking	Optional
Bluetooth	Optional
Unit Dimensions	15.0X8.0X4.6cm
Unit Weight	Approx. 213g
Packing	1 pc / Gift box; 24 pcs / Carton
Carton Size	Approx. 34X34X30cm
Carton Weight	Approx. 13kg

We are a leading manufacturer that specialize in home medical devices over 20 years, which covers infrared thermometer, digital thermometers, digital blood pressure monitor, breast pump, medical nebulizer, pulse oximeter, and POCT lines.

OEM / ODM services are available.

All products are designed and manufactured inside the factory under ISO 13485 and are certificated by CE MDR and pass US FDA, Canada Health, TGA, ROHS, REACH, etc.

In 2023, Joytech's new factory became operational, occupying over 100,000㎡ of built-up area. With a total of 260,000㎡ dedicated to R&D and the production of home medical devices, the company now boasts state-of-the-art automated production lines and warehouses.

We warmly welcome all the customers' visting. It's only 1 hour by high-speed rail from Shanghai.
