Factory Direct OEM Electronic Infrared Forehead Thermometer CE MDR Infrared Thermometer

Share to:

Factory Direct OEM Electronic Infrared Forehead Thermometer CE MDR Infrared Thermometer

DET-3020 hammer-style forehead thermometer with optional dual probe and distance detection ensures safe, fast, and accurate non-contact measurement.

Unit Dimension:	14.8 x 4.7 x 6.9 cm
Battery:	2 pcs of AAA 1.5V batteries
Nature of Business:	Medical Device Manufacturer & Global Exporter
Service Offering:	OEM / ODM Available
Availability:



Inquire Add to Basket

Model:
DET-3020
Brand:
Joytech / OEM

Product Description

Parts & Functions

Specifications

Factory Profile

The DET-3020 Forehead Thermometer stands out with its unique hammer-style design, combining ergonomic comfort with advanced infrared technology. Similar to the DET-3012, this model offers optional dual probe and distance detection functions to ensure highly accurate non-contact temperature measurement.

With a 1-second reading, 30-reading memory, and clear display options, it provides both speed and reliability for home or professional use.

Optional features such as Bluetooth connectivity, talking function, and backlight enhance convenience, while the automatic power-off and replaceable battery design ensure long-lasting performance.

Whether for daily fever monitoring or professional body temperature management, the DET-3020 delivers accuracy, safety, and ease of use in one compact device.

Safty Notice: Please read all instructions carefully before using the device.

Measure on forehead

Non-contact

30 reading memories

1 second reading

Dual scale with °C/°F

Acoustic reading signal

Talking optional

Backlight optional

Bluetooth optional

Replaceable battery

Distance sensor optional

Automatic power-off

FAQ

Q: May I have sample?

Yes, samples are available but delivery cost should be collected.

Q: Would it be possible to buy from you under our own brand name?

Yes, we are factory and can make your brand as per your need for LOGO or color customization.

Q: Do you have MOQ for customization orders?

Yes, MOQ is 1000 pcs. You should pay for the customization fee if less than 1000pcs.

Q: What are differences among your forehead thermometer?

Joytech forehead thermometers are with similar functions for option as per your need. They differ from appearance designs such as the LCD size, the button position and probe radians that meet different measurement habits.

Q: Do you have certificate for this model?

Joytech non contact thermometers including DET-3020 are CE MDR approval as well as US 510k listing approval.

The DET-3020 Forehead Thermometer is designed in a unique hammer style and equipped with optional dual probe and distance detection features, ensuring safe and accurate non-contact measurement. Each part is carefully designed for intuitive operation and reliability.

1. Probe – Detects infrared light from the forehead for accurate, non-contact measurement.

2. Test Button – Initiates temperature measurement with a simple press for quick results.

3. Memory Button – Allows easy access to stored temperature readings for trend tracking.

4. Setting Button – Adjusts measurement modes, unit selection (°C/°F), and other customizable functions.

5. Battery Cover – Protects and secures the replaceable battery compartment, ensuring long-term use.

DET-3020 description

Model	DET-3020
Type	Infrared Forehead
Response Time	1 second
Memory	30 Memories
Range	34.0°C- 43.0°C (93.2 °F-109.4 °F)
Accuracy	±0.2°C,35.5°C -42.0°C(±0.4°F,95.9 °F-107.6°F)
Obeject Mode	Yes
Fever Alarm	≥ 37.8°C (100.0°F)
Backlight	Optional
Display size	25.8x23.7mm
Power Source	2“AAA” batteries
Probe Cover	No
Battery Life	About 3000 readings
Unit Dimension	15.7x4.5x6.5cm
Unit Weight	Approx. 131grams
Packing	1 pc / Gift box;60 pcs / Carton
Carton Dimension	Approx. 55x49.5x38cm
Carton Weight	Approx. 12kg

We are a leading manufacturer that specialize in home medical devices over 20 years, which covers infrared thermometer, digital thermometer, digital blood pressure monitor, breast pump, medical nebulizer, pulse oximeter, and POCT lines.

OEM / ODM services are available.
All products are designed and manufactured inside the factory under ISO 13485 and are certificated by CE MDR and pass US FDA, Canada Health, TGA, ROHS, REACH, etc.

In 2023, Joytech's new factory became operational, occupying over 100,000㎡ of built-up area. With a total of 260,000㎡ dedicated to R&D and the production of home medical devices, the company now boasts state-of-the-art automated production lines and warehouses.

We warmly welcome all the customers' visting, it's only 1 hour by high-speed rail from Shanghai.
