Crystal Layer Screen Accurate Forehead Thermometer with Distance Indicated Light DET-3018a

Share to:

Crystal Layer Screen Accurate Forehead Thermometer with Distance Indicated Light DET-3018a

DET-3018a forehead thermometer with distance indicated light and crystal layer display for accurate, durable, and user-friendly measurement.

Unit Dimension:	15.5 x 3.92 x 4.94 cm
Battery:	2 pcs of AAA 1.5V batteries
Nature of Business:	Medical Device Manufacturer & Global Exporter
Service Offering:	OEM / ODM Available
Availability:



Inquire Add to Basket

Model:
DET-3018a
Brand:
Joytech / OEM

Product Description

The Joytech DET-3018A Forehead Thermometer is a non-contact temperature screening tool comprehensively upgraded in professionalism and durability. Building on the acclaimed DET-3018, it introduces the crucial Distance Indicator Light and is equipped with a unique Crystal Layer LCD Display. These core enhancements, combined with one-second measurement and data storage, ensure a more accurate, intuitive, and reliably durable temperature-taking experience in various scenarios, from daily family care to professional high-frequency screening.

1. The DET-3018A ensures accuracy from the source of operation with its built-in Distance Indicator Light, which guides users to maintain the optimal measurement range in real-time. Its Crystal Layer LCD Display significantly enhances visibility under strong light and resists daily scratches, ensuring readings are sharp and clear in any lighting condition and remain durable over time.

2. Utilizing non-contact infrared technology, it completes a forehead temperature measurement within one second, entirely avoiding cross-contamination risks. This efficient and hygienic method makes it ideal for checking children, family health self-monitoring, or use in public places requiring rapid screening, such as schools, clinics, or corporate entrances.

3. The device supports storing up to 30 historical readings for easy tracking of temperature trends. Furthermore, it offers a rich selection of optional interaction modes: Vibration Alerts for quiet environments, Voice Broadcast for accessible use, a 4-Color Backlight for intuitive temperature range feedback, and Bluetooth Connectivity for data syncing and smart management.

4. The addition of the Crystal Layer Display is a milestone in product durability. It provides scratch protection similar to a phone screen, and its anti-reflective properties make reading data outdoors or in bright rooms easier. This design significantly enhances the device's reliability during frequent use or while being carried around, extending the product's service life.

Safty Notice: Please read all instructions carefully before using the device.

Measure on forehead

Vibration optional

30 reading memories

1 second reading

Dual scale with °C/°F

Talking optional

4 colors backlight optional

Bluetooth optional

Parts & Functions

The DET-3018a Forehead Thermometer is designed with user-friendly functions and an upgraded appearance. Each part is thoughtfully engineered to ensure accurate, safe, and convenient measurement.

1. Probe – The main sensor for detecting temperature. The hole below is an optional distance detection sensor for enhanced accuracy.

2. Test Button – Specially designed button for quick and easy measurement.

3. Voice Switch – Convenient push button to turn the talking function on or off.

4. Setting Button – Allows adjustment of thermometer settings according to user preference.

5. Battery Cover – Secure compartment for replacing batteries.

6. Display – LCD display with crystal layer for improved clarity, durability, and visibility.

DET-3018 description

Specifications

Model No.	DET-3018a
Measuring Site	Forehead(Forehead Mode)
Reference Body Site	Oral（This thermometer converts the forehead temperature to display its “oral equivalent”）
Operation Mode	Forehead Mode(Adjusted Mode)
Accuracy	Forehead mode: ±0.2℃ (0.4℉) during 35.5℃~42.0℃ (95.9℉~107.6℉) at 15℃~35℃ (59.0℉~95.0℉) operating temperature range ±0.3℃ (0.5℉) for other measuring and operating temperature range Object mode:±4%or ±2℃(4℉) whichever is greater
Measure Time	Approximately 1 Second
Measuring Range	Forehead mode:34.0℃~43.0℃ (93.2℉~109.4℉) Object mode:0℃~100℃(32℉~212℉)
Display Resolution	0.1℃ or 0.1℉
Storage Condition	-25℃ ~ 55℃ (-13℉ ~131℉), 15%~95%RH, non-condensing Atmospheric Pressure:700hPa~1060hPa
Ambient Operating Range	Forehead/Object mode: 5℃~40℃ (41℉ ~104℉), 15%~85%RH, non-condensing Atmospheric Pressure:700hPa~1060hPa
Expected Service Life	Three years
Dimension	15539.249.4mm
Weight	Approximate 97grams(with batteries)
Power Source	DC3V(2XAAA batteries)
Battery Life	Approx. 3000 readings
Ingress Protection Rating	IP22

Factory Profile

Joytech: Trusted in Home Healthcare for Over 20 Years

• 24 years of OEM & ODM expertise.
• 3 manufacturing centers with 260,000㎡ automated facilities and 2000㎡ automated warehouses.
• 30+ production lines & 100+ patented innovations.
• ISO 13485, MDSAP, BSCI certified quality systems.
• Full customization for global brands, including Fortune 500 partners.

Joytech: Trusted in Home Healthcare for Over 20 Years

Joytech Healthcare exhibits at major global trade shows every year, including:

• WHX Dubai (formerly Arab Health), Dubai

• WHX Miami (formerly FIME), Miami, USA

• Hong Kong Electronics Fair, Hong Kong

• ABC Kids Expo, USA

• KIMES, Seoul, Korea

• MEDITEX Bangladesh, Dhaka

• Hospitalar, São Paulo, Brazil

• Canton Fair, China

• MEDICA, Düsseldorf, Germany

We are committed to meeting partners worldwide at leading international medical and consumer health exhibitions.

Joytech: Trusted in Home Healthcare for Over 20 Years

FAQ

Q1: Can functions like vibration, voice, and backlight be turned off individually? Will they drain the battery?

A1: These optional functions can individually be enabled or disabled. Users can flexibly configure them based on the actual usage scenario. The device itself employs low-power design and features an Auto Power-Off function. These additional functions consume minimal power only when enabled, having a negligible impact on overall battery life, so there's no need to worry about power consumption.

Q2: What are the specific advantages of the Crystal Layer Display compared to a standard screen?

A2: The Crystal Layer Display offers three core advantages: First, Superior Clarity—its anti-reflective coating reduces ambient light glare, making readings easier in sunlight or under lights. Second, Enhanced Durability—the surface is harder, effectively preventing scratches from everyday items like keys or fabric. Third, Long-Lasting New Look—the protective layer prevents the screen surface from becoming hazy over time, maintaining the device's professional appearance.

Q3: Is the Bluetooth function practical for average home users?

A3: The Bluetooth function brings possibilities for digital advancement in family health management. For families with infants, young children, or individuals with chronic conditions, automatically syncing temperature data to a mobile app via Bluetooth allows them to generate long-term temperature charts, facilitating observation of illness progression or providing precise historical records to doctors during visits. This represents a leap from single measurements to systematic health management.
