Description
DET-1013 infrared ear thermometer is suitable for family who has high expectation for the ear thermometer functions. 3 color backlight and bluetooth functions are all available.
The thermometer is CE MDR approval.
OEM / ODM services available for use.
CE MDR infrared ear thermometer.
1. Probe Cover (optional)
2. Probe
3. Test Button
4. Mode Button
5. Battery Cover
6. Setting Button
Compact design with 2 small buttons on the side. You can put it into your pocket.
Specifications
| Model Number | DET-1013 |
| Description | Infrared Ear Thermometer |
| Certification | Company Certificates | ISO13485, MDSAP, BSCI, TGA, TUV |
| Product Certificates | CE, FDA 510K, RoHs, Reach |
| Measuring Range | 32.0℃~43.0℃ (89.6℉~109.4℉) |
| Specification | Memory | 30 Sets Memories |
| Response Time | 1 second |
| Laboratory Accuracy | ±0.2℃ (0.4℉) during 35.0℃~42.0℃ (95.0℉~107.6℉) at 15℃~35℃ (59.0℉~95.0℉) operating temperature range ±0.3℃ (0.5℉) for other measuring and operating temperature range |
| Clinical Accuracy | Clinical bias：0.12℃(0.2 )
Clinical repeatability：0.12℃(0.2 )
Limits of agreement:0.80℃(1.4 ) |
| Display | LCD Display, Size of 23.3mm*21.7mm |
| Fever Alarm | when over 37.8℃ (100.4ºF) |
| Battery | 2*AA battery |
| DC3V |
| Battery life | Approx. 1 year/6000 readings |
| Dimension | 10.6 cm x 3.3 cm x 4.7 cm (L x W x H) |
| Weight | Approx. 34 grams including battery |
| Functions | Date/Time | Yes |
| ℃/℉ Switchable | Yes |
| Auto-Off | Yes |
| Error measurement message | Yes |
| 3 Color Backlight | Optional |
| Talking | / |
| Bluetooth | Optional |
Features
●Measure in ear
●Bluetooth optional
●Probe covers optional
●Replaceable battery
●Easy probe cover remove design
●Automatic power-off
●30 reading memories
●1 second reading
●Dual scale with °C/°F
●Beeps
●Backlight optional
FAQ
Q: How does an infrared ear thermometer work?
A: Infrared ear thermometers work by measuring the infrared heat emitted from the eardrum. The thermometer has a sensor that detects this heat and converts it into a temperature reading.
Q: Are infrared ear thermometers accurate?
A: Yes, infrared ear thermometers are generally accurate when used correctly. However, factors such as earwax buildup, incorrect positioning of the thermometer, or external factors like cold temperatures can affect accuracy.
Q: How do I use an infrared ear thermometer?
A: To use an infrared ear thermometer, gently insert the probe into the ear canal and aim it towards the eardrum. Ensure a snug fit and press the button to take the temperature reading. Follow the manufacturer's instructions for specific guidance.
Q: Can I use probe covers from other brand?
A: The thermometer must only be used with Joytech thermometer probe covers.
Q: Do you have certificate for this model?
A: Joytech non contact thermometers including DET-3020 are CE MDR approval as well as US 510k listing approval.
