NB-1100
OEM available
1 Introduction
Intended use/Indications for use:
The Compressor Nebulizer include air compressor that provide a source of compressed air with a jet (Pneumatic) nebulizer to convert certain inhalable drugs into an aerosol form for inhalation by a patient. The device can be used with adult or pediatric patients(2 years and older) in the home, hospital, and sub-acute settings.
Name of disease or condition:
Asthma, Chronic obstructive pulmonary disease (COPD),Cystic fibrosis, Respiratory tract
infection, etc disease of respiratory system.
Patient population:
adults or children (2 years and older)
Intended user:
healthcare person or lay person
2 Safety Instructions
Cautions
1. The product should never be left unattended when plugged in.
2. The patient is an intended operator, close supervision is necessary when this product is used by, or near children or disabled individuals.
3. Operate the device only as intended. Do not use the device for any other purpose
4. Always ensure that the air vents are not blocked or obstructed in any way.
5. Do not disassemble the nebulizer or attempt to repair it; any attempt for repair should be completed only by qualified technical personnel.
Warning
1. The nebulizer can work with the solution or suspensions only, but not with emulsions or high viscosity drugs.
2.Operate the device only as intended. Do not use the nebulizer for any other purpose or in a manner inconsistent with these instructions.
3.For type, dose, and regime of medication follow the instructions of your physician or licensed healthcare practitioner.
4.Never use any liquid in the nebulizer other than those prescribed by your doctor. Liquids such as cough medicines or essential oils can harm both the machine and the patient.
3 Technical Data
SPECIFICSTIONS | |
Model: | NB-1100 |
Type: | Compressor Nebulizer |
Power supply: | AC 230V, 50 Hz |
Input Power: | ≤ 80VA |
Operating Mode: | Continuous Operation |
Sound Level: | ≤ 65dB(A) |
Gas Flow Volume Rate: | ≥6.5L/min |
Dimensions: | Approx. 10.5" (w) × 6.2" (h) × 4.1" (d) (267.9mm × 157.3 mm × 104.6 mm) |
Weight: | Approx. 1.55kg (Compressor only) |
Operating Temperature/Humidity/ Atmospheric Pressure | +5°C to +40°C (+41°F to +104°F)/15% to 90% RH/86 kPa to 106 kPa |
Storage and Transport Temperature/Humidity/ Atmospheric Pressure | –20°C to +55°C (–4°F to +131°F)/5% to 93% RH/70 kPa to 106 kPa |
Normal Working Pressure: | 50kPa~180kPa |
Abnormal Working Pressure: | 190kPa~320kPa |
Functions: | Power cord storage, Nebulizer kit storage |
Classification: | Class II equipment, Type BF applied part |
Contents: | 1 Compressor nebulizer unit, 5 Air Filters, 1 Owner’s manual |
The Standard Accessories: | Air filter(×5 pcs) |
Applied Parts: | Mask, Mouthpiece |
Accessible Parts: | Shell of Compressor |
Fuses: | 5JF 1.6AL 250V |
Adjustable amount of fog.
Fast heat dissipation.
A compressor nebulizer with storage space for neb accessories.
1. Large amount of fog, time saving
2. Large storage space for accessories
3. Super long air duct, free movement
4. Low residue and high utilization rate
5. Low noise for quiet using at home
6. Double suction mode of mask and suction nozzle
Q: Are you trading company or factory?
A: Joytech Healthcare is a factory manufacturing home-care medical devices such as digital thermometers, digital blood pressure monitors, nebulizers, pulse oximeters, etc. We will show you our factory price and factory direct quality products.
Q: Where is you factory located?How can I visit there?
A: Our factory is located in Hangzhou, Zhejiang Province, China, about 1 hour by train from Shanghai. All our clients from home or abroad are warmly welcome!
Q: How can I get some samples?
A: Please feel free to contact us by e-mail or Alibaba for any samples, We are honored to offer your samples.
Q: When will you make the delivery?
A: For formal orders we can make the delivery within 30-45 working days according to the size of you order. For sample orders, it can be delivered within 3 -15 days as per customization or not.
Q: What is your MOQ?
A: Please contact the customer service, and the price is negotiable for large quantity.
