Infrared Forehead Thermometer High Accuracy Baby Thermometer with Distance Indicated Light DET-3017a

Share to:

Infrared Forehead Thermometer High Accuracy Baby Thermometer with Distance Indicated Light DET-3017a

DET-3017a Digital Forehead Thermometer combines distance indication with reliable infrared technology, ensuring safe, accurate, and user-friendly temperature measurement.

Unit Dimension:	15.5 x 3.92 x 4.94 cm
Battery:	2 pcs of AAA 1.5V batteries
Nature of Business:	Medical Device Manufacturer & Global Exporter
Service Offering:	OEM / ODM Available
Availability:



Inquire Add to Basket

Model:
DET-3017a
Brand:
Joytech / OEM

Product Description

The Joytech DET-3017a Digital Forehead Thermometer represents a thoughtful upgrade, directly addressing a core user need in non-contact measurement. By integrating an innovative built-in distance indicated light, it actively guides users to the optimal position, significantly enhancing ease of use and measurement confidence. This upgrade, combined with rapid one-second readings and versatile smart features, makes it a reliable and adaptable tool for both vigilant family health guardians and efficient professional screening.

1. The defining upgrade is the built-in distance indicator light. This visual guide activates during measurement, clearly signaling when the device is held within the ideal range. This directly tackles the primary source of user error in infrared thermometers, ensuring consistent and reliable readings by eliminating guesswork.

2. Utilizing advanced infrared sensor technology, the thermometer provides a stable temperature reading in approximately one second from a safe, non-contact distance. This method is completely hygienic, preventing cross-contamination, and is ideal for quick checks on children, screening visitors, or use in clinical settings where speed and safety are paramount.

3. To suit diverse environments and user preferences, the DET-3017a offers multiple feedback modes: standard audible beeps, discreet vibration alerts for silent operation, and a clear talking function that announces the result. The optional Bluetooth connectivity allows for seamless data syncing to a health app for long-term trend tracking and record-keeping.

4. The device features a high-contrast display and an intuitive 4-color backlight system that instantly indicates normal or elevated temperature ranges. It also stores up to 30 previous readings, allowing for easy tracking of temperature trends over time for an individual or multiple family members.

Safty Notice: Please read all instructions carefully before using the device.

Bluetooth optional

Vibration optional

30 reading memories

Distance sensor

1 second reading

Automatic power-off

Dual scale with °C/°F

Talking optional

4 colors backlight optional

Parts & Functions

The DET-3017a Digital Forehead Thermometer is thoughtfully designed with user-friendly components to ensure safe, accurate, and convenient operation. Each part plays a key role in delivering reliable performance:

1. Probe – Captures infrared signals from the forehead for accurate, non-contact temperature measurement.

2. Test Button – Starts the measurement process with a single press for quick results.

3. Voice Switch – Allows you to enable or disable the talking function for flexible use.

4. Setting Button – Adjusts measurement units (°C/°F) and other customizable options.

5. Battery Cover – Provides easy access for replacing batteries, ensuring long-term usability.

6. Display – Large and clear screen to show temperature readings, backlight colors, and additional indicators.

DET-3017a description

Specifications

Model	DET-3017a
Measuring Site	Forehead (Forehead Mode)
Reference Body Site	Oral（This thermometer converts the forehead temperature to display its "oral equivalent"）
Operation Mode	Forehead Mode (Adjusted Mode)
Accuracy	Forehead mode: ±0.2℃ (0.4℉) during 35.5℃~42.0℃ (95.9℉~107.6℉) at 15℃~35℃ (59.0℉~95.0℉) operating temperature range ±0.3℃ (0.5℉) for other measuring and operating temperature range Object mode: ±4% or ±2℃ (4℉) whichever is greater
Measure time	Approximately 1 Second
Measuring Range	Forehead mode: 34.0℃~43.0℃ (93.2℉~109.4℉) Object mode: 0℃~100℃ (32℉~212℉)
Display Resolution	0.1℃ or 0.1℉
Storage Condition	-25℃~55℃ (-13℉~131℉), 15%~95%RH, non-condensing Atmospheric Pressure: 700hPa~1060hPa
Ambient Operating Range	Forehead / Object mode: 5℃~40℃ (41℉~104℉), 15%~85%RH, non-condensing Atmospheric Pressure: 700hPa~1060hPa
Expected Service Life	Three years
Dimension	155 x 39.2 x 49.4mm
Weight	Approximate 97grams (with batteries)
Power Source	DC3V (2 x AAA batteries)
Battery Life	Approx. 3000 readings
Ingress Protection Rating	IP22

Factory Profile

Joytech: Trusted in Home Healthcare for Over 20 Years

• 24 years of OEM & ODM expertise.
• 3 manufacturing centers with 260,000㎡ automated facilities and 2000㎡ automated warehouses.
• 30+ production lines & 100+ patented innovations.
• ISO 13485, MDSAP, BSCI certified quality systems.
• Full customization for global brands, including Fortune 500 partners.

Joytech: Trusted in Home Healthcare for Over 20 Years

Joytech Healthcare exhibits at major global trade shows every year, including:

• WHX Dubai (formerly Arab Health), Dubai

• WHX Miami (formerly FIME), Miami, USA

• Hong Kong Electronics Fair, Hong Kong

• ABC Kids Expo, USA

• KIMES, Seoul, Korea

• MEDITEX Bangladesh, Dhaka

• Hospitalar, São Paulo, Brazil

• Canton Fair, China

• MEDICA, Düsseldorf, Germany

We are committed to meeting partners worldwide at leading international medical and consumer health exhibitions.

Joytech: Trusted in Home Healthcare for Over 20 Years

FAQ

Q1: How does the distance indicator light actually improve accuracy?

A1: Accuracy in non-contact thermometers is highly dependent on maintaining the correct measurement distance. The distance indicator light provides real-time, visual feedback. When the light shows the correct signal, it confirms the sensor is at the proper range to capture the infrared energy accurately. This eliminates the common error of measuring too close or too far, which can distort readings.

Q2: Is the one-second reading fast enough for screening a line of people?

A2: Absolutely. The one-second measurement speed is specifically engineered for high-throughput scenarios. When combined with its non-contact operation, it enables efficient, rapid screening without creating bottlenecks, making it an excellent tool for entrance screening at workplaces, schools, or public events.

Q3: What is the main benefit of the Bluetooth function for a family?

A3: The optional Bluetooth function transforms the thermometer from a momentary checking tool into a family health management system. It automatically logs each reading with a timestamp in a smartphone app. This allows parents to easily track fever patterns over an illness for each child, create accurate health records to share with pediatricians, and monitor recovery progress with clear charts.
