Infrared Forehead Thermometer High Accuracy Baby Thermometer with Distance Indicated Light DET-3017a

Share to:

Infrared Forehead Thermometer High Accuracy Baby Thermometer with Distance Indicated Light DET-3017a

DET-3017a Digital Forehead Thermometer combines distance indication with reliable infrared technology, ensuring safe, accurate, and user-friendly temperature measurement.

Unit Dimension:	15.5 x 3.92 x 4.94 cm
Battery:	2 pcs of AAA 1.5V batteries
Nature of Business:	Medical Device Manufacturer & Global Exporter
Service Offering:	OEM / ODM Available
Availability:



Inquire Add to Basket

Model:
DET-3017a
Brand:
Joytech / OEM

Product Description

Parts & Functions

Specifications

Factory Profile

The DET-3017a Digital Forehead Thermometer is an upgraded version of the DET-3017, enhanced with a built-in distance indicated light for improved measuring accuracy.

This feature ensures users always maintain the correct measuring range, solving one of the key challenges of non-contact thermometers.

Designed with a clear display and ergonomic form, it delivers fast 1-second readings and can store up to 30 groups of memories for convenient health tracking.

Optional functions such as Bluetooth connectivity, vibration alerts, and a 4-color backlight provide additional customization, while the talking function makes it suitable for multi-scenario use, including family care and professional environments.

With automatic power-off, dual scale (°C/°F), and hygienic non-contact measurement, the DET-3017a ensures safety, reliability, and convenience in every reading.

Safty Notice: Please read all instructions carefully before using the device.

Bluetooth optional

Vibration optional

30 reading memories

Distance sensor

1 second reading

Automatic power-off

Dual scale with °C/°F

Talking optional

4 colors backlight optional

FAQ

Q: Are you trading company or factory?

Joytech Healthcare is a factory manufacturing home-care medical devices such as digital thermometers, digital blood pressure monitors, nebulizers, pulse oximeters, etc. We will show you our factory price and factory direct quality products.

Q: How about the quality of your products?

We have been in business for over 20 years, starting with digital thermometers then moving into digital blood pressure and glucose monitoring.

We currently work with some major companies in the industry such as Beurer, Laica, WalMart, Mabis, Graham Field, Cardinal Healthcare and Medline to name a few, so our quality is trustworthy.

Q: Would it be possible to buy from you under our own brand name?

Yes, we are factory and can make your brand as per your need for LOGO or color customization.

The DET-3017a Digital Forehead Thermometer is thoughtfully designed with user-friendly components to ensure safe, accurate, and convenient operation. Each part plays a key role in delivering reliable performance:

1. Probe – Captures infrared signals from the forehead for accurate, non-contact temperature measurement.

2. Test Button – Starts the measurement process with a single press for quick results.

3. Voice Switch – Allows you to enable or disable the talking function for flexible use.

4. Setting Button – Adjusts measurement units (°C/°F) and other customizable options.

5. Battery Cover – Provides easy access for replacing batteries, ensuring long-term usability.

6. Display – Large and clear screen to show temperature readings, backlight colors, and additional indicators.

DET-3017 description

Model	DET-3017a
Measuring Site	Forehead (Forehead Mode)
Reference Body Site	Oral（This thermometer converts the forehead temperature to display its "oral equivalent"）
Operation Mode	Forehead Mode (Adjusted Mode)
Accuracy	Forehead mode: ±0.2℃ (0.4℉) during 35.5℃~42.0℃ (95.9℉~107.6℉) at 15℃~35℃ (59.0℉~95.0℉) operating temperature range ±0.3℃ (0.5℉) for other measuring and operating temperature range Object mode: ±4% or ±2℃ (4℉) whichever is greater
Measure time	Approximately 1 Second
Measuring Range	Forehead mode: 34.0℃~43.0℃ (93.2℉~109.4℉) Object mode: 0℃~100℃ (32℉~212℉)
Display Resolution	0.1℃ or 0.1℉
Storage Condition	-25℃~55℃ (-13℉~131℉), 15%~95%RH, non-condensing Atmospheric Pressure: 700hPa~1060hPa
Ambient Operating Range	Forehead / Object mode: 5℃~40℃ (41℉~104℉), 15%~85%RH, non-condensing Atmospheric Pressure: 700hPa~1060hPa
Expected Service Life	Three years
Dimension	155 x 39.2 x 49.4mm
Weight	Approximate 97grams (with batteries)
Power Source	DC3V (2 x AAA batteries)
Battery Life	Approx. 3000 readings
Ingress Protection Rating	IP22

We are a leading manufacturer that specialize in home medical devices over 20 years, which covers infrared thermometer, digital thermometer, digital blood pressure monitor, breast pump, medical nebulizer, pulse oximeter, and POCT lines.

OEM / ODM services are available.
All products are designed and manufactured inside the factory under ISO 13485 and are certificated by CE MDR and pass US FDA, Canada Health, TGA, ROHS, REACH, etc.

In 2023, Joytech's new factory became operational, occupying over 100,000㎡ of built-up area. With a total of 260,000㎡ dedicated to R&D and the production of home medical devices, the company now boasts state-of-the-art automated production lines and warehouses.

We warmly welcome all the customers' visting, it's only 1 hour by high-speed rail from Shanghai.
