ECG Blood Pressure Monitor OEM Available DBP-6673B

Package:
Type:
Availability:
  • DBP-6673B

  • Joytech / OEM


PRODUCT  DESCRIPTION


ECG


Specifications


Product Description

ECG Blood Pressure Monitor

Model

DBP-6673B

Display

LCD Digital Display Size: 95.5mm×54.5mm (3.76" x 2.15")

Measurement Method

Oscillometric Method

Pressurization

Automatic Pressurization

BP Measurement Range

Systolic Pressure

60~260mmHg

Diastolic Pressure

40~200mmHg

Pulse

30~180Beats/Minute

BP Measurement Accuracy

Pressure Accuracy

±3mmHg or ±2% above 200 mmHg

Pulse Accuracy

30~39Beats/Minute   ±5BPM

40~180Beats/Minute  ±5%

ECG Measurement Method

Single-channel ECG

ECG Measurement Range

bandwidth

0.67~40Hz

Heart Rate

30 ~ 199 Beats/Minute

Measuring Time

30 Seconds

ECG Measurement Accuracy

Heart Rate

±5%

Memory

2x150 BP Memories in Two Groups with Date and Time

2x20 ECG Memories in Two Groups with Date and Time

BP Function

Irregular Heartbeat Detection

WHO Classification Indicator

Last 3 Tests Average

ECG Function

Atrial Fibrillation Indicator

Normal Sinus Rhythm,Bradycardia,Tachycardia

Other Function

Automatic Power-Off

Low Battery Detection

Voice

Backlight

Power Source

3A AA batteries

Battery Life

Approximately 2 months at 3 tests per day

Unit Weight

Approx.549g (19.4 oz.) (including battery)

Unit Dimensions

Approx.142.5 x 107.2 x 44mm (5.61" x 4.22" x 1.73" )(L x W x H)

Optional Cuff Circumference

Fits arm circumference 22cm~36 cm

Fits arm circumference 22cm~42 cm

Fits arm circumference 32cm~48 cm, select one.

Electrode sheet material

stainless steel

Operating Environment

Temperature

10℃ ~ 40℃ (50℉~104℉)

Humidity

15% ~ 93%RH

Pressure

Atmospheric Pressure, 800hPa~1060hPa

Storage Environment

Temperature:

-25℃~55℃ (-13℉~131℉)

Humidity

≤ 93%RH

Bluetooth

Frequency

2.4GHz(2400-2483.5Mhz)

Type Of Antenna

Built-in Onboard Antenna

Transmission power

About 3dbm

Classification:

Internal Powered Equipment, Type BF  Cuff is the Applied Part

Ingress Protection Rating

IP21  Indoor Use Only



One set including:

One pc of ECG blood pressure monitor DBP-6673B,

One English User's manual

One pc of arm cuff

One storage case

DBP-6673B


FACTORY PROFILE


factory1

简介

证书

设备


OUR EXHIBITION

展会


Safety Notice

Important Instructions Before Use

1. Do not confuse self-monitoring with self-diagnosis. Blood pressure measurements should only be interpreted by a health professional who is familiar with your medical history.

2. Contact your physician if test results regularly indicate abnormal readings.

3. If you are taking medication, consult with your physician to determine the most appropriate time to measure your blood pressure. NEVER change a prescribed medication without first consulting with your physician.

4. Individuals with serious circulation problems may experience discomfort. Consult your physician prior to use.

5. For persons with irregular or unstable circulation resulting from diabetes, liver disease, arteriosclerosis or other medical conditions, there may be variations in blood pressure values measured at the wrist versus at the upper arm. Monitoring the trends in your blood pressure taken at either the arm or the wrist is nevertheless useful and important.

6. People with vasoconstriction, liver disease or diabetes, women with weak pulses, pregnant women should consult their doctor before measuring their own blood pressure, different values may be obtained due to their condition.

7. People suffering from arrhythmias such as atrial or ventricular premature beats or atrial fibrillation only use this ECG Blood Pressure Monitor in consultation with your doctor. In certain cases oscillometric measurement method can produce incorrect readings.

8. Too frequent measurements can cause injury to the patient due to blood flow interference.

9. The cuff should not be applied over a wound as this can cause further injury.

10. DO NOT attach the cuff to a limb being used for IV infusions or any other intravascular access, therapy or an arterio-venous (A-V) shunt. The cuff inflation can temporarily block blood flow, potentially causing harm to the patient.

11. The cuff should not be placed on the arm on the side of a mastectomy. In the case of a double mastectomy use the side of the least dominant arm.

12. Pressurization of the cuff can temporarily cause loss of function of simultaneously used monitoring equipment on the same limb.

13. A compressed or kinked connection hose may cause continuous cuff pressure resulting in blood flow interference and potentially harmful injury to the patient.

14. Check that operation of the unit does not result in prolonged impairment of the circulation of the patient.

15. Product is designed for its intended use only. Do not misuse in any way.

16. Product is not intended for infants or individuals who cannot express their intentions.

17. Prolonged over-inflation of the bladder may cause ecchymoma of your arm.

18. Do not disassemble the unit or arm cuff. Do not attempt to repair.

19. Use only the approved arm cuff for this unit. Use of other arm cuffs may result in incorrect measurement results.

20.This product is not intended for users wearing implantable pacemakers

21. The system might produce incorrect readings if stored or used outside the manufacturer's specified temperature and humidity ranges.

22. Do not use the device near strong electrical or electromagnetic fields generated by cell phones or other devices, they may cause incorrect readings and interference or become interference source to the device. Do not use the device during patient transport outside healthcare facility for interference source existing as well.

23. Do not mix new and old batteries simultaneously

24. Replace batteries when Low Battery Indicator“”appears on screen. Replace both batteries at the same time.

25. Do not mix battery types. Long-life alkaline batteries are recommended.

26. Remove batteries from device when not in operation for more than 3 months.

27. Do not insert the batteries with their polarities incorrectly aligned.

28. Dispose batteries properly; observe local laws and regulations.

29. Do not touch the electrode of this product to other conductors (including grounding).

30. During ECG measurement, if your skin or hands are too dry, please moisten it with a damp towel. Implement measurement.

31. When the electrode surface is dirty, please wipe it with a damp cloth or alcohol cotton, at least once a month.

32. During ECG measurement, please do not use the product in reverse directions with your left and right hands.

33.The performance of automatic ecg sphygmomanometer may be affected by extreme temperature, humidity and altitude.

34. Advising operator that Instruction manual/ Booklet must be consulted

35.The time required for the device to warm from the minimum storage temperature (-25°C) between use until the device is ready for use at Ambient Temperature 20°C: about 2 hours.

36.The time required for the device to cool from the maximum storage temperature (70°C) between use until the device is ready for use at ambient temperature (20 °C) : about 2 hours
